More Space

openSUSE moved to BLS some time ago using the bootloaders systemd-boot and GRUB2-BLS that nowadays is mostly a repackaging of the traditional GRUB2, as the main patches are already merged since 2.16.

This decision also required more space in the ESP partition, as now the kernel and initrds of all snapshots are stored in /boot/efi/$TOKEN, where $TOKEN can be the machine-id, opensuse-tumbleweed or opensuse-microos, depending on the installation. For new installations, this is not a problem since the installer (YaST or Agama) will recommend a large (1 GB) partition; for older installations, the migration can be problematic, to the extreme that if the partition cannot be resized. It is advisable to keep the old GRUB2-EFI bootloader.

But if we decide to use systemd-boot, there is a escape hatch: XBOOTLDR

A New Partition

XBOOTLDR is a new partition that can live anywhere in the disk. The ESP has some limitations in that regard, and usually is the first partition in the system. If present, systemd-boot will look for the menu entries and the kernel / initrds in there, freeing the ESP of that responsibility.

The file system of this partition needs to be also FAT32, like the ESP as this is a limitation of the UEFI, and during the creation needs have a specific GPT identifier (GUID). With fsdisk, we can create a new partition and assign the type 142 or xbootldr; this will assign the correct GUID into the partition table and systemd-boot will recognize it.

Mount Points

Because of this new partition, the mount points needs to change too. As commented, the traditional place where openSUSE put the ESP is in /boot/efi but now we have two places. The UAPI recommendation is to have always the boot entries and the kernel in /boot, and only if there is a separated partition for the boot loader, then this will be placed in /efi. Because this is the case now, we will need to update out /etc/fstab:

UUID=4165-E891 /efi  vfat utf8,dmask=0077,noexec,nodev,nosuid,nosymfollow 0 2 UUID=414C-528C /boot vfat utf8,dmask=0077,noexec,nodev,nosuid,nosymfollow 0 2

Change the UUID to point to the correct device.

sdbootutil can find both partitions and write in the correct place now, depending if we are updating the bootloader or adding new entries.

Now we can move the boot entries and the kernel directories, both placed in the old /boot/efi/loader path. We can manually move it into the new partition, just keep loader/random-seed and loader/loader.conf in the old place, but the rest of the loader/ directory can be moved.

More information about a more detailed description can be found in the following section:

Further Documentation

• Migrating from GRUB2-EFI
• MicroOS FDE
• UAPI.1 The Boot Loader Specification
